Connecting the Router to Your Computer
A. First, connect the power adapter to the receptor at the back panel of the
DSL-502T and then plug the other end of the power adapter to a wall outlet or
power strip. The Power LED will turn ON to indicate proper operation.
B. Insert one end of the cable into the Ethernet port on the back panel of the
DSL-502T and the other end of the cable to an Ethernet Adapter or available
Ethernet port on your computer.
ADSL port -
connect to
ADSL line
USB port,
connect USB
cable here
and install
Ethernet port -
connect to
Ethernet cable
Please read the User's Manual for instructions on how to use
the USB port.
2
Factory
Reset
button
Power input -
connect to power
adapter
