D-Link DSL-514 Schnellinstallationsanleitung

This product can be set up using any
current web browser, i.e., Internet
Explorer 6.x, Netscape Navigator 7.x.
Before Your Begin
1.
If you purchased this Router to share your high-speed Internet connection with other
computers, you must have either an Ethernet-based Cable or a DSL Router with an
established Internet account from an Internet Service Provider (ISP).
2.
It's best to use the same computer that is connected to your router for configuring the DSL-
514 ADSL Router. The DSL-514 acts as a DHCP server and will assign all the necessary IP
address information on your network. See at the Quick Installation Guide or the Manual on the
CD-ROM for setting each network adapter to automatically obtain an IP address.
Check Your Package Contents
These are the items included with your DSL-514 purchase:
If any of the above items are missing, please contact your reseller.
©2003 D-Link Systems, Inc. All rights reserved. Trademarks or registered trademarks are the property of their respective
holders. Software and specifications subject to change without notice. DSL-514.ADSL Router
• DSL-514 ADSL Router
• CD-ROM (containing Manual and Warranty)
• Ethernet Cable
• 9V AC, 1A Power Adapter
•ADSL Cable (standard telephone cable)
different voltage rating
will damage and void
the warranty for this
product.
1
DSL-514
ADSL Router
Using a power
supply with a
