Channel assignment information
For the functions, the unit uses eight channels. The first DMX channel is defined with the the OASE DMX
control unit.
Channel Description
DMX-Channel + 0 Access of the red LEDs
DMX-Channel + 1 Access of the green LEDs
DMX-Channel + 2 Access of the blue LEDs
DMX-Channel + 3 Not used
DMX-Channel + 4 Master, Access of the lumination of all RGB
channels
DMX-Channel + 5 Not used
DMX-Channel + 6 Strobe
DMX-Channel + 7 Shutter
Please check the master value when you don't see the LEDs shining. The minimum value is at least 1
for the master (DMX-Channel + 4) to see the LEDs shining.
Setting the water jet
Attention! Dangerous electrical voltage.
Possible consequences: Death or severe injury.
Protective measures:
► Prior to reaching into the water, switch off the mains voltage to all units used in the water.
► Switch off the mains voltage prior to carrying out work on the unit.
1. Undo the Allen screws (36) on both sides of the unit foot (23) using the Allan key (18) and bring the
Jumping Jet Rainbow Star (1) to the desired inclination angle.
2. Retighten the Allan screws (36).
3. Set the pump flow rate.
The flow rate of electrically controlled pumps is set with the control unit (e.g. "In Scenio FM Master
3"), the flow rate of pumps without control feature is set manually by means of a slide in the pump
suction or pressure area.
4. Setting the water jet (Fig. I - K)
Align the jet diaphragm (37) in the hood of the Jumping (1) Jet such that the water jet passes the
centre of the jet diaphragm (37). Ensure that the water jet is not deflected by the water jet diaphragm
(37).
Values
0 ... 255, Density of red LEDs
0 ... 255, Density of green LEDs
0 ... 255, Density of blue LEDsc
0 ... 255, Density of all LEDs
0 = Strobe disabled,
255 = Strobe enabled
0 = Shutter closed
255 = Shutter opened
