3.4 Battery change

• Two 1,5V AA batteries are required.
• The battery compartment is below the pouch.
• Simply remove the pouch from the compartment during battery change.
• Unscrew the battery lid.
• Remove old batteries and dispose of in accordance with applicable federal,
state/provincial and local regulations and directive.
• Replace with new batteries. Pay attention to the correct orientation of each
battery.
• Close the compartment and secure the lid with the screw.
• Do not expose batteries to direct sunlight, heat or fi re.
There is a risk of explosion!

4. Use

Every Easy-Click pole section has its own activation button to start the pump. It's most useful to use the
lowest button that is close to your lower hand. The triangle shape makes it easy to reach in every corner.
1. Before beginning a new cleaning job or when using a new pad, press
the activation button for four seconds to pre-moisten the TriPad.
Use circular motions to dampen the entire surface of the TriPad.
During the cleaning process use as little liquid as possible. If you need to
re-moisten the TriPad, hold the activation button for about 1 second per
square metre.
You don't need to use much of the Glass Cleaner. Because the TriPad is
made from high performing microfi bre material, it only needs to be damp
to achieve the best cleaning results.
1
2. Start by cleaning the window frames. Turn the right edge of
the TriPad to next frame side and move it to the next corner.
Turn again the edge to next frame, move down and repeat that
for all 4 corners of the window (see also picture on page 7).
3. Clean the inner area of the window. You can clean from side to
side or from top to bottom. Always turn the triangle head to the
side beyond.
10 www.ungerglobal.com/stingray
Stingray Cleaning System
Installation / Use
3
Stingray Cleaning System
Information
5. Maintenance & Storage
After use, clean and dry all extension poles with a microfi bre cloth. Read and follow the washing
instruction on the pad. Store the system safely. Do not lean extended poles against a wall. An upright
position with cleaning head up is recommended. The Stingray Cleaning System fi ts into standard
toolholders that are mounted to a wall.
The temperature in the storage room should be in the range of 5°C - 40°C max.

6. Technical Data

Length/shipping weight main unit
Length/weight short extension pole
Length/weight long extension pole
Max. cleaning height
Dimension cleaning head / microfi bre pad
Material Microfi bre Pad
Batteries needed
Stingray Professional Glass Cleaner* (150ml)
Stingray Professional Glass Cleaner* reach
*powered by Scotchgard™, 3M
** Internal testing
2.
1.
3.
2 2
4...
51 cm, 750g
63 cm, 440g
124 cm, 270g
2x long, 1x short extension pole
(app. 3,00m)
25 x 25 x 0,25 cm
70% polyester, 30% polyamide
2x 1,5V AA
<5% anionic tensides, dyes and fragrance
up to 150 sqm**

7. Environmental information

• The outer packing material (except the liquid pouch) can be
recycled. Please do not place the packaging into ordinary refuse
trash bin for disposal, but arrange for the proper recycling.
• Old appliances contain valuable materials that can be recycled.
Please arrange for the proper recycling of old appliances.
• Batteries contain substances that must not enter the environ-
ment. Please dispose of your old batteries in accordance with
applicable federal, state/provincial and local regulations.
• The battery must be removed from the appliance before it is
scrapped. It has to be disposed safely.
www.ungerglobal.com/stingray 11
