Configure The Bar-Code Scanner (Lfh3300 Only) - Philips SPEECHMIKE series Benutzerhandbuch

Windows task bar. To manually start the
program, open the Windows start menu in
Windows and select
Speech Control > Philips Device Control
Center.
On the Device tab, click on
4
update.
Click the Import button and select the
5
folder with the firmware files to be
imported.
Click the Upgrade
6
firmware.
• The firmware upgrade takes about 30
seconds.
• During firmware upgrade the indicator lights
of the SpeechMike will be flashing.
Warning
B
Do not disconnect the dictation microphone
from the computer during firmware upgrade.
This might damage your product.
5.3 Configure the bar-code scanner
(LFH3300 only)
The SpeechMike barcode scanner is pre-
configured with the keyboard language US
English and the suffix "carriage return" (CR).
Before using the barcode scanner for the first
time, it is necessary to adapt it to your local
keyboard language. To change the scanner
configuration, start the application
exe on the installation CD.
For information about customizing the barcode
module, refer to the Advanced Barcode Scanner
Configuration manual on the installation CD
provided with your SpeechMike.
User manual
All Programs > Philips
Firmware
button to install the new
Barcodeconfig.
13
