Tab. 1:
Status messages
normal operation
Tab. 2:
Status messages
battery
Tab. 3:
Status messages
tamper protection
contact
(tampering)
Functions and operation
Approved 2017-08-16

Light signals

The outside knob has a transparent cover through which the LEDs can shine. The
signals and their meanings are explained in the following tables.
Normal operation
There is no fault present in the normal operating mode.
Signal
yellow
green
red
Battery change required
The battery is used up or depleted.
Signal
yellow 5 s yellow 5 s yellow
red 5 s red 5 s red
Monitoring via tamper protection contact (tampering)
The battery is replaced or a tampering attempt is carried out on the knob.
Signal
red 0,125 s red
red 0,125 s red
Meaning
Card is held in front.
Door can be unlocked or locked.
Blocked, no authorisation.
Meaning
Battery is very low.
Battery is empty.
Meaning
Battery being replaced.
10x
Tampering attempt on the knob.
10x
EN 39
