Connection
3.2
PE
L1
L2
L3
3.3
GB - 10

Connection of an inverter to the R5-Rectifier

Filter
L1
L1
L2
L2
L3
L3
L1
L2
R5-Rectifier
Attention! The minimum permissible current limiting resistor amounts to 2 Ohm.
An undershooting may lead the equipment damage.

Connection of the temperature monitoring

12
11
K1
U
The internal temperature monitoring has to be analysed and shut-down the
machine, if the contactwill be opened.
24 V DC
+ 10 %
0,6 A
+ -
L3
PE
T1 T2
-
+
T2 T1
PE
DC-FI
+ +
– –
U
V W
M
~
3
L1
L2
L3
T1
T 2
