Programming - Simons Voss Technologies 3078 Kurzanleitung

PROGRAMMING.

Please proceed as follows to program the CompactReader.
1. Create a new lock (G2) and select the card interface under Configura-
tion and click on the "Card interface" checkbox under "Edit
properties
2. Create new users and select "G2 card"
3. Set all the required card authorisations in the matrix.
4. Place the lock and the CompactReader at a distance of approx. 10-
15 cm from the programming device and program using LSM 3.1 SP
1 (or higher) and SmartCD.G2 (firmware: 9.10.4.40 or higher).
Then install the CompactReader and its (associated) lock. Please ensure
that the assigned components (CompactReader and lock) do not get
mixed up as otherwise the function cannot be guaranteed.
Configuration/data".
- 19 -
Lock
