Cubix™ 2.0 QRG
Menu Options
Main Level
DMX Address
Auto Programs
Auto Program Speed
Sound-Active Mode
DMX Linking
Starting
Address
Master/Slave
Connection
DMX Values
7-CH
Channel Function
Programming Levels
512
AUTO
S--
SNd
The Cubix™ 2.0 can work with a DMX controller when linked by DMX
serial connections. Instructions for connecting and configuring this product
for DMX operation are in the User Manual. If you are not familiar with DMX,
download the DMX Primer from www.chauvetlighting.com.
To ensure full access to all channels in each DMX mode, the highest
recommended DMX address is 506.
The Cubix™ 2.0 uses the DMX data connection for its Master/Slave mode.
Instructions for connecting and configuring this product for Master/Slave
operation are in the User Manual.
1
Colors
2
Strobe
3
Motor Rotation
4
Auto Programs
d 1–d512
Sets the DMX starting address
Sets Auto program
S 1–S100
Selects Auto program speed (slow to fast)
Sets Sound-Active mode
Value
Percent/Setting
000 ó 004 No function
005 ó 028 Red
029 ó 056 Green
057 ó 084 Blue
085 ó 112 Cyan
113 ó 140 Purple
141 ó 168 Yellow
169 ó 197 White
198 ó 224 3-Color switching
225 ó 255 7-Color switching
000 ó 004 No function
005 ó 255 0–30 Hz
000 ó 127 Rotation with indexing
Back and forth with
128 ó 255
increasing distance
000 ó 014 Blackout
015 ó 020 Auto program 1
021 ó 026 Auto program 2
027 ó 032 Auto program 3
033 ó 038 Auto program 4
039 ó 044 Auto program 5
045 ó 050 Auto program 6
051 ó 056 Auto program 7
057 ó 062 Auto program 8
063 ó 068 Auto program 9
069 ó 074 Auto program 10
4
Description
Side Lenses
Middle Lens
