Troubleshooting the Mower

PROBLEM
Mower cut is uneven.
Mower cut is rough look-
ing.
Engine stalls easily with
mower engaged.
For all other issues, see authorized dealer.

Specifications

Engine *
Briggs & Stratton
Intek Series
TM
Displacement 656 cc
Professional Series
TM
Displacement 724 cc
All Engines
Oil Capacity 64 oz (1,9 L)
Spark Plug Gap 0.030 in. (0,76 mm)
Spark Plug Torque 180 in-lbs (20 Nm)
Chassis
Fuel Tank Capacity 3 gal (11,4 L)
Inflation Pressure Front Wheels: 22 psi (1,52 bar)
Rear Wheels: 12 psi (0,83 bar)
Transmission
Hydro-Gear EZT
® ®
Mower
Width of Cut 42" (107 cm)
46" (117 cm)
48" (122 cm)
Cutting Height 1.5" - 4.5" (3,8 - 11,7 cm)
24
LOOK FOR
Rider tires not inflated equally or
properly.
Engine speed too slow.
Ground speed too fast.
Engine speed too slow.
Ground speed too fast.
Cutting height set too low.
Discharge chute jamming with cut
grass.
REMEDY
See Maintenance section.
See engine speed control to FAST.
Decrease ground speed.
Set engine speed control to FAST.
Decrease ground speed.
Cut tall grass at maximum cutting.height during first pass.
Cut grass with discharge pointing toward previously cut
area.
