5 Presentation of the tool

Before using the tool, read the instructions on its specific operation and safety conditions applicable. The tool and its
accessories must be used only for the work they were designed for. Any other use is strictly forbidden.
1 Jaw locking system
2 Rotating head
3 Trigger
4 Battery or cable connector
5 Information plate
6 Protection cap - Connection by mini USB port
7 "Battery" LED: battery charging indication
8 "Cycle" LED: crimping cycle state indication
9 "Maintenance" LED
10 ON/OFF button
5.1 Charging and installing the battery
5.1.1

Charging the battery

• CONNECT THE CHARGER TO MAINS.
• INSERT THE BATTERY INTO THE
CHARGER.
• DURING BATTERY CHARGING.
• REMOVE THE BATTERY.
2 3
1
Ensure the charger is adapted to the network it will be connected to.
Ensure the battery is inserted properly into the charger
The battery LED on the charger flashes green. During charging, the
area around the charger must be clear to prevent any risk of fire due to
heating.
The battery LED on the charger is lit in green steady: the battery is
fully charged. To warranty an optimum lifetime, we recommend to
charge the battery at maximum capacity every time. The charging time
is about 30min
5 6
4
7
8
9
10
