The tool bears a label describing special signs. They provide important information about the product or instructions of use.
Compliant with European safety directives
and standards.
Wear glasses.

2 Technical data

Model
Reference
Battery power supply
Power input
Force delivered by the machine to ensure crimping
Crimping capacity:
PER / PEX tubes:
Multilayer tubes:
Steel tubes (stainless or galvanised steel):
Copper tubes:
Jaw rotation
Weight (without battery ; without jaw / with battery ; with jaw)
Machine dimensions with battery ; without jaw
length / height / width (mm)
Carry case dimensions - length / height / width (mm)
Information on sound and vibration emissions
Sound emission:
Acoustic pressure level at operator's ears: L
Peak acoustic pressure level at operator's ears: LpPeak
Acoustic power level: LwA
Uncertainty K
pA
As per the NF EN ISO 15744 standard – tests on idle work cycles
Vibration emission
Weighted hand-arm acceleration values m/s
On the trigger
Estimated uncertainty
As per the NF EN ISO 20643 standard – tests on idle work cycles
NOTES:
• Read the instructions carefully before using this tool.
• The manufacturer reserves the right to improve his products and change their specifications without prior notice.
• The specifications can vary according to the country.
pA
2
Please read the original instructions.
Wear gloves.
VIPER M21+/ML21+
2535XX
18V DC 1.5 Ah Li-ion 27 Wh
Max. 20 kN
Ø 12 to Ø 32/40 mm.
Ø 12 to Ø 32/40 mm.
Ø 12 to Ø 28 mm.
Ø 12 to Ø 28 mm.
M21+ : 1,8 kg / 2,2 kg
ML21+ :1,7 kg / 2,1 kg
M21+ : 260 / 265 / 85
ML21+ : 315 / 115 / 75
M21+ : 680 / 425 / 160
M21L+ : 600 / 360 / 140
79 dB (A)
89 dB (C)
86 dB (A)
1.16 m/s
0.20 m/s
EN
400 W
360°
3 dB
2
2
