5. Detector Board

5
Pulse Count
4
Light Control
Recording Control
3
Time Adjustment
Options
. LED Selector
(3 pins: Top, Center, Bottom)
. Sensitivity Adjustment
High
„VR"
3. Dwell Time Adjustment
Min.
„VR"
Adjustable
from  to 40 sec.
PULSE
1
2
J2
VR2
J4
Description
A. Top + Center w/black cap: Upon walk-testing:
Light blinking (disadvantages: Easy to identify
as a security system.)
J
B. Center + Low w/black cap: No light blinking
while detecting. (advantages: less obvious)
A. To raise sensitivity: Turn clockwise to detect
longer distance and wider pattern.
Low
B. To lower sensitivity: Turn counter clockwise
for detection in narrow areas.
For closure period of N.C/N.O relay connected to
an alarm panel, light control or recording control
Max.
of time lapse VCR, etc.
A. Max. time: Turn counter clockwise
B. Min. time: Turn clockwise
Top + Center pins of „J4" must be selected
to adjust the time setting.
N.C.
N.O.
JP2
J1
VR1
8
6
Output Terminals
1
LED Selector
2
Sensitivity
Adjustment
