SCOUT PRO
No. Designation
1. Platform
2. PRINT Unit button
3. Display
4. Lockswitch
5. ON/ZERO Off button* On/Off, Zero, enters menu, accepts menu settings.
6. USB or RS232 port
7. Security Bracket
8. Power Input Jack
9. 7-segment LCD
10. Brackets
11. G
12. N
13. %
14. PC
15. kg
16. dwt
17. g
18/20. oz t
18. t
19. ct
20. oz
21/20. lb:oz
21. lb
22. •
*
23
-
24.
25.
26.
Note:* This button is configured either as "ON/ZERO Off" or "ON / 0/T Off" depending
on country. There is no difference in functionality. In this manual, "ON/ZERO Off" is
used as example.
Function
Weighing platform, either round or rectangular.
Prints data, scrolls through units, steps through
menu options.
LCD display with icons.
Locks certain menu functions, located under
balance.
Optional kit for either RS232 or operation USB.
Part of balance for optional external cable and lock.
Connector for AC adapter.
Part of 6-digit LCD display.
Auxilliary indication.
Indicates specific gravity
Indicates Newtons.
Indicates percent weighing.
Indicates pieces during parts counting.
Indicates weight in kilograms.
(not used)
Indicates weight in grams.
(not used)
Indicates totalize mode
(not used)
Indicates weight in ounces.
(not used)
Indicates weight in pounds. (certain models)
Decimal point.
Stability indicator, indicates stable weight and
Display Hold when flashing.
Negative sign.
(not used)
Battery indicator flashes when battery is down to
EN-7
