4. IN CASE OF pROBlEMS

Fault observed Description of fault
Radio icon flashes on main screen. Remote control reception problem
Or
The remote control no longer operates the HRV
system.
[Radio icon] and "rF" flash on main screen. Radio pairing fault
[Radio icon flashes on main screen] Filters clogged in HRV system.
The ventilation unit is operating in degraded
mode.
[Battery icon flashes on main screen] Remote control battery level low.
On the home screen, -- is displayed instead of Internal sensor fault (MMI probe)
the interior temperature. The HRV system continues to operate normally.
[Fault/key icon flashes on main screen] Malfunction Press INFO to view the error code
(Err):
Err 182:
exhaust motor
Err 183:
supply motor
Err 239:
soiled air exit sensor
Err 240:
fresh air inlet sensor
Err 251:
soiled air inlet sensor
Err Exxx: Ubio
Other malfunctions: remove and re-insert batteries, reset to factory settings (see paragraph 3, menu 11).
If the problem persists, contact your installer or your vendor.

5. TEChNICAl DETAIlS

Radio transmitter, 868.3 Mhz
Power supply: 2 x AAA 1.5V batteries
Solution
Move the remote control closer to the HRV
unit Check the quality of the connection: press
the INFO button to view the signal quality (1
to 3 bars).
If the fault is persistent, re-do the radio pairing
(see chapter 2 User information).
Re-do the radio pairing
(see chapter 2 User information).
If the fault is persistent:
- Check that the radio PCB is correctly slot-
ted into the Cube unit (see chapter 2 User
information).
Replace the filters.
Refer to the instructions for the HRV system.
Replace the batteries.
Contact your installer.
Turn the electric supply off then on again.
If the fault is persistent:
One of the two motors
- Turn off the electric supply,
is defective.
for 30 minutes then restart,
The ventilation system
- Or contact your installer.
is stopped.
One of the three
temperature sensors
is defective. The HRV
system is operating in
degraded mode.
Fault on Ubio heating
module: refer to Ubio
instructions.
22
6. RECYClING
WEEE End of product life
- This product must not be disposed of with household waste. At the end of its life or if replaced, it should
be deposited at a recycling or collection centre, or returned to a vendor.
- ALDES is a member of the Eco Systèmes eco-cluster www.ecosystemes.fr
- ALDES designed this product to be recycled easily. By participating in selective waste sorting,
you are contributing to the recycling of this product and to protecting the environment.
- Take used batteries and accumulators to your nearest suitable collection point.
Do not dispose of them in nature.
- For any further information, consult the eco-cluster concerned.
REACh European Directive
To the extent of our knowledge, this article this article contains no candidate list substances to more than. 0.1% of its weight
as specified on the list maintained by ECHA.
7. WARRANTY AND lIABIlITIES
The multi-function radio remote control was designed and produced for use in ventilation systems.
All other use is considered improper use. The manufacturer shall not be held responsible and declines all liability in the event
of damage to persons or property as a result of improper use.
The manufacture shall not be liable for damage caused by:
• The non-respect of instructions concerning safety, settings and use contained in this manual.
• The use of parts not supplied or specified by the manufacturer (the installer assumes full responsibility for the use of
such parts). Use only official spare parts provided by the manufacturer.
• Normal wear and tear.
A. Safety instructions
• It is important to supervise children to ensure they do not play with the device.
• Alterations to the Cube radio remote control are prohibited.
• Keep this manual close to the multi-function remote control throughout its service life.
There is a risk of explosion if the batteries are replaced with others of the incorrect type. Dispose of dead batteries in
accordance with instructions.
Do not leave the batteries in the remote control if it is left unused for long periods.
