Mounting Instruction - R82 Flamingo Montageanleitung

Mounting instruction

Mounting Calf support and Seat infi ll on a Flamingo
Mounting calf support (A)
Open the calf support and tighten it around the foot support bars
on the fl amingo. Fasten the calf support with the velcro.
Mounting Seat Infi ll (B)
Mount the Seat infi ll by pushing it down into the hole in the seat.
The raised portion of the infi ll must be located towards the front of
the seat.
When mounting the Seat infi ll, please be careful not to get
fi ngers caught.
Do not tighten the calf support so much, that the foot support
bars bends.
The calf support must not be too loose, so a child gets tang-
led up.
A
R82 A/S • Parallelvej 3 • DK-8751 Gedved • www.R82.com
Never leave the user unattended. Ensure constant super-
vision by an adult.
Carefully read the care label on the calf support to maintain
and wash correctly.
The latest version of the mounting instruction is always
available online: www.R82.com
B
