Fitting the parallel guide (� g. 3)
Screw the clamps (26) securely to the parallel
guide (7/28) using the � nger screws (15/27).
Secure the parallel guide to the workbench
(1) and tighten in the required position using
the � nger screws.
Fitting the mitre guide (� g. 4)
Push the mitre guide (16) into the slot in the
workbench. Loosen the adjustment screw
(24), turn the mitre guide to the required
angle and retighten.
If necessary, � t the rail (20) to the mitre guide
using the two � nger screws
