Boost -MOBILE12-SET Bedienungsanleitung Seite 4

Start singing into the microphone and adjust the volume to the desired level.
When the indicator lamp on the mic lights up, you have to replace the battery.
Don't use the microphone close to the speaker in order to avoid feedback.
KARAOKE Function
This feature is available with any input. Play a track through AUX/USB/TF/ Bluetooth, connect a
microphone and sing along.
Built-in REC function
1. Plug a microphone into the MIC IN input.
2. Insert a USB/SD card into the corresponding port. Press Input selector button and select USB/SD mode.
3. If the USB/SD card is plugged into the speaker for the first time, the system will automatically create a
folder named 'record' to save the recorded files.
4. When you are ready to record, press REC button to record the sound of the wireless or wired
microphone.
USB/TF Operation
Keep the speaker away from high temperatures, strong magnetic fields and any equipment that could
generate interference. If the speaker stops working, switch it off and on again, or unplug USB/SD/MMC
card and re-plug it. The speaker should be back to normal status.
The maximum size of USB/SD device that can be connected is 32 GB.
Supported music formats: MP3, WMA
BLUETOOTH OPERATION
1. Turn on the unit and press the input selector button on unit to select the Bluetooth function.
2. Activate the Bluetooth feature on the external device to be paired.
3. Initiate a search for devices. The device shows up as "MOBILE12-SET" or "MOBILE15-SET".
4. Press the   to start playing and the buttons  and  for the selection of songs.
CHARGING THE UNIT
This speaker has a high capacity battery. Please use the supplied lead for charging.
The power adapter has an indicator light that will illuminate red when the speaker is on charge. It takes
around 6-8 hours to fully charge the speakers. Disconnect the power adaptor as soon as the battery is fully
charged.
Note: When the battery of the speaker is low, please charge it within 48 hours.
Specifications
Subwoofer
Output power
Frequency range
S/N ratio
Sensitivity
Bluetooth frequency range
VHF frequency range
Power supply
Battery
©Copyright LOTRONIC 2018
BOOST-MOBILE12-SET
12"/30cm-100Hz
600W
100Hz - 20kHz
96db (+/-2db)
2402 – 2480MHz
174-216MHz
9V 1.2A via supplied 100-240Vac 50/60Hz mains adaptor
Lithium-ion battery 1800mAh DC 7.4V
BOOST-MOBILE-SET
BOOST-MOBILE15-SET
15"/38cm
700W
>80dB
98dB (+/-2dB)
4
