Technical Specification - Techne IFB-101 Bedienungsanleitung

Temperature range
Temperature control stability at 450°C
Temperature uniformity at 450°C
Internal dimensions
Loading capacity
Typical heat-up time 20°C to 450°C
Compressed air supply pressure
Air consumption
Nominal Heater Power
Heater type
Control system
Protection systems
Electrical safety protection
Fluidised medium
External dimensions
Nett weight (less fluidised medium)
Gross weight (less fluidised medium)
Electrical supply

teChnICal SpeCIFICatIOn

diameter
depth
working depth
1/3 of vol.
1/3 of C.S.Area
20°C to 600°C
maximum
at 450°C
height
width
depth
50°C to 600°C
+5°C
10°C
310mm
760mm
350mm
9 litre
25758 mm 2 (typically ø179mm).
100 minutes
210 minutes
204-1030kPa(30-150psi)
160 l/min
70 l/min
6KW
ceramic knuckle heating element
3 term PID temperature controller
+ thermocouple sensor.
Solid state control.
Independent over temperature cut-out.
Fluidising air interlock
Door interlock.
Control circuit fuse.
Power fuse.
50kg Aluminium Oxide,
Part No F0885
915mm
950mm
640mm
75kg
99kg
See rating plate for details
