About the digital input/output of the UA-1D

Input
The UA-1D has two digital input connectors: OPTICAL IN
and COAXIAL IN. However, it is not possible to use both
OPTICAL IN and COAXIAL IN simultaneously. If signals are
simultaneously input to both connectors, the signal applied to
OPTICAL IN is given priority. If you want to use COAXIAL
IN, disconnect the cable from the OPTICAL IN connector.
Output
Output from the UA-1D takes places in one of the following
two ways:
• If a signal is being input through the digital input connector
The signal being input through the digital input connector
will be output to both OPTICAL OUT and COAXIAL OUT.
The audio signal from the computer will not be output to
OPTICAL OUT or COAXIAL OUT.
OPTICAL has priority
• If no signal is being applied at the digital input connector
The audio signal from the computer will be output to both
OPTICAL OUT and COAXIAL OUT.
In order to use the UA-1D to play back audio data from
your computer, there must be no input signal arriving at
the digital input connector. In other words, you must either
connect nothing to the digital input connector, or turn off
the power of the connected device.
26
COMPUTER
COMPUTER
