DX Error Code
Room Sensor Open or Short
Indoor Coil Sensor Open
Outdoor Coil Sensor Open
Compressor Overload/ Indoor Coil Sensor Short/ Outdoor Coil Sensor Short
Low Refrigerant Charge/ Gas Leak/ Outdoor Abnormal
Water Pump Fault
Outdoor Coil Sensor Exist (MS mode)
Hardware Error (Tact Switch Pin Short)
Indoor Fan Feedback Error
EEPROM Error
CW Error Code
Room Sensor Open or Short
Pipe Water Sensor Open or Short
Pipe Water Temperature Poor
Pipe Water Temperature Bad/ Fault
Water Pump Error
Hardware Error (Tact Switch Pin Short)
Indoor Fan Feedback Error
NOTE:
• Function 3, 4, 5, 12 are not applicable for Roof Top models.
• Function 6 (Dry Mode) is not applicable for Roof Top models.
• Function 12 (Automatic Air Swing) mode is not applicable for ducted models.
13. CONNECTION WIRES GUIDE
Mainboard
SB 125 board
08A board
UCW W2 board
Error Description
Error Description
Wire Type
UL 2547 AWG 26
UL 2547 AWG 26
UL 2547 AWG 26
2
Maximum Wire Length (m)
10
15
15
E1
E2
E3
E4
E5
E6
E7
E8
E9
EE
E1
E2
E4
E5
E6
E8
E9
