Humidity-Temperature Sensor KWL-FTF
Please note:
Connection
A1
GND
A2
GND
The KWL-FTF needs an initialisation period of around 2 minutes before a measurement
value is issued
3.3 Connection to Helios BUS (for KWL compact units with easyControls)
– Connection according to wiring diagram SS-1074.
Addressing
If multiple humidity-temperature sensors are connected, the addressing must be adjus-
ted. There must be no double address allocations for sensors 1-8! (see DIP switch table;
wiring diagram SS-1074).
KWL-FTF
Relative humidity 0 - 100 % 0 - 10 V max. 20 mA
GND
Temperature 0 - 40 °C 0 - 10 V max. 20 mA
GND
