spEEDviEw parTs lisT
receiver assembly Diagram
19.
20.
headset assembly Diagram
2.
1.
spEEDviEw sET-up anD usEr insTrucTions:

Box Contents:

• 1 x speedivew Unit
• 1 x receiver Unit
• 1 x transmitter Unit + speedbutton
• 1 x Lithium-ion battery Pack
• 2 x speedroll replacement film
• 1 x spindle
• 1 x sticker sheet
• 1 x Microfibre cleaning cloth.
18
instruction manual_aw_2.indd 18
Transceiver assembly Diagram
17.
16.
18.
15.
14.
4. 5.
3.
7.
9.
8.
1. Track cover
6.
2. spindle
3. motor unit
4. Ptfe slider + Mounting plate
5. Track
6. Dual anti-Fog lens
7. track + cover fixing Grommits
8. Goggle
9. Triple layer Foam
10. Dual layer strap
11. receiver pouch
12. receiver
13. speedbutton
14. Transmitter Base unit
15. 2 x aaa Batteries
16. Gasket
17. Transmitter cover
18. receiver Base unit
19. lithium-ion Battery
20. receiver cover
12.
11.
10.
