Genelec G One Betriebsanleitung Seite 7

G Two
Active Loudspeaker
MAINS INPUT
50 / 60 Hz 50 W 230 V~
MADE IN FINLAND
www.genelec.com
Figure 1. Control and connector layout on the rear panel of a G Two.
Bass
The "Bass" control offers three attenuation levels
for the bass response below 1 kHz, usually neces-
sary when the loudspeakers are placed near room
boundaries or other situations when the bass sounds
boomy and too dominant. The attenuation levels are
-2 dB, -4 dB and -6 dB. The -6 dB attenuation is se-
lected by setting both "Bass" switches to "1".
WARNING
ELECTRIC SHOCK HAZARD. DO NOT OPEN.DO NOT SUBJECT
TO WATER OR MOISTURE. NO USER SERVICEABLE PARTS
INSIDE. REFER SERVICING TO QUALIFIED PERSONNEL.
USE EARTHED MAINS CONNECTION ONLY.
AVERTISSEMENT
RISQUE DE CHOC ÉLECTRIQUE. NE PAS OUVRIR. NE PAS
EXPOSER À L'EAU OU L'HUMIDITÉ. AUCUN COMPOSANT À
L'INTÉRIEUR REMPLAÇABLE PAR L'UTILISATEUR. ADRESSER
TOUTE RÉPARATION À UN PERSONNEL QUALIFIÉ. CET
APPAREIL DOIT ÊTRE RACCORDÉ À LA TERRE.
1
0
LED OFF
TABLETOP
BASS -2 dB
-4 dB
-6 dB
INPUT
ON OFF
SERIAL NUMBER
REFLEX PORT
THREADS FOR
CEILING AND
WALL MOUNTS
TONE CONTROLS
CONNECTOR PANEL
(HORIZONTAL)
Iso-Pod™ TABLE
STAND
The factory setting for all tone controls is "0" to
give a flat anechoic frequency response. Always
start adjustment by setting all switches to "0" posi-
tion. Measure or listen systematically through the
different combinations of settings to find the best
tonal balance.
English 7
