Important! The fitting must be installed, flushed
and tested after the valid norms!
Assembly
1. Flush through the supply pipes.
2. Place the mixer including the sealing
washer in position on the basin.
3. Slide the fixation piece including the washer
over the threaded pins and tighten the nuts.
4. Connect the supply pipes to the isolation
valves; cold right - hot left.
5. 38030000 / 38035000 Connect the pull rod
to the pop-up waste.
The hot and cold supplies must be of equal
pressures.
Technical Data
This mixer series-produced with
waterdimmer® (flow limiter).
Rate of flow with waterdimmer:
Rate of flow without waterdimmer:
Operating pressure:
Recommended operating pressure:
MPa
Test pressure:
(1 MPa = 10 bars = 147 PSI)
Hot water temperature:
Recommended hot water temp.:
The aerator is not equal to DIN EN 246
English
5 /min 0,3MPa
9 l/min 0,3 MPa
max. 1 MPa
0,1 – 0,5
1,6 MPa
max. 80° C
65° C
Hansgrohe single lever mixers can be used
together with hydraulically and thermically
controlled continuous flow heaters if the flow
pressure is at least 0,15MPa.
If the continuous water heater causes any
problems or there is not enough flow of water,
the waterdimmer® (5a) located behind the
aerator must be removed.
To adjust the hot water limiter on single lever
mixers, please see page _1b.
No adjustment is necessary when using a
continuous flow water heater.
Spare parts see page 4
1 handle
1.1 screw cover
1.2 hollow set screw M6x10 DIN916 96029000
2 flange
3 nut
4 cartridge cpl.
5 seal
6 aerator cpl.
7 fixing set
8 connection hose 470 mm
9 pop up rod
10 spout cpl. 38030000/38031000
11 spout cpl. 38035000
Special accessories
X special tool set 58085000
(order as an extra)
38094000
96762000
96763000
97209000
96764000
95008000
95387000
13961000
96321000
96657000
97363000
97688000
