50 Linear D

Technical specifications

EN
Analogue section
Input impedance 47 kOhm
Maximum gain setting +0 dB, +10 dB, +18 dB, +20 dB
switchable on bottom side
Analogue frequency
10 Hz (-0.3 dB) to 35 kHz (-1 dB)
response
Analogue S/N ratio > 100 dB at +0 dB gain
Analogue THD
< 0.001 % at 6 mW/300 Ohm
Channel separation
> 80 dB/10 kHz
Power output 300 Ohm/200 mW
≠
60 Ohm/400 mW
≠
Output impedance
Pre-out 50 Ohm
≠
Phones out 5 Ohm
≠
Audio Connections Neutrik headphone sockets with gold-plated contacts
≠
1 x pre-out
≠
2 x phones out
≠
gold-plated RCA sockets with teflon insulation
≠
Mains connections 230 V AC
Fuse 250 mA, Slo-Blo
Power consumption in ca. 15 W through internal, regulated power supply
operation
Enclosure dimensions 110 mm x 280 mm x 44 mm
W x D x H
Weight
1.5 kg net
Digital-analogue converter
Digital Inputs 1 x Toslink (priorised)
≠
1 x RCA 75 Ohms
≠
Sampling rate digital 32 kHz; 44.1 kHz; 48 kHz; 88.2 kHz; 96 kHz; 192 kHz
Resolution 24 Bit
Chipset ESS Sabre K2M
Analog filter
Silver Mica
Max. output voltage DAC 1.8 V eff.
Special feature Automatic fallback to analog if no digital audio
signal is present
Linear D
capacitors
51
EN
