1. UNLOADING

The device should be transported in vertical position, and it should be properly secured and packed. The manufacturer
ships the device on a special wooden platform, secured with cardboard angle sections and foil.

2. PROPERTIES OF THE DEVICE

2.1. Purpose

"Rafał B" is a universal cooling device used to store and display a wide assortment of grocery products previously cooled
to storing temperature. Guaranteed temperature within the refrigerating cabinet ranges between +2ºC and +8ºC with
ambient temperature ranging between +15ºC and +25ºC and relative air humidity of up to 60%.

2.2. Description of the device

"Rafał B" rack is equipped with dynamic cooling, automatic defrosting and automatic condensate evaporation. The rack
is also equipped with electronic thermostat optionally cooperating with temperature recording module enabling to record
and signal too low and too high temperature within the device. The rack is equipped with built-in cooling aggregate. "Rafał
B" device is equipped with 3 rows of display shelves (with changed depth), with regulated depth and suspension angle.
The interior of the rack is illuminated from the top. It is possible to additionally illuminate each of the shelves. Our devices
are made according to modern technologies and have all certifi cates required by law.
Contents
1. UNLOADING
2. PROPERTIES OF THE DEVICE
2.1. Purpose
2.2. Description of the device
2.3. Technical data
3. PREPARING THE DEVICE FOR EXPLOITATION
3.1. Requirements concerning the place of installation
3.2. Connection and actuation
4. EXPLOITATION
4.1. Temperature regulation
5. MAINTENANCE
5.1. Cleaning and maintenance
6. SERVICE
6.1. Fault identifi cation and repair
6.2. SERVICE
7. THERMOSTAT SERVICE
7.1. "IGLOO" thermostat
7.2. "CAREL" thermostat
This sign signifi es information of particular meaning for user security and for proper device
exploitation.
10
User manual RAFAŁ B
RAFAŁ B
List of Figures
10 Fig.1 Construction of the device
10 Fig.2 Removing the wooden platform
10 Fig.3 Mounting the hook in the frame
10 Fig.4 Rack shelf system
11 Fig.5 Control panel
11 Fig.6 Cleaning the condenser
11 Fig.7 Exchange of the fl uorescent lamp
12 Fig.8 Assembly/disassembly of the glass side
13 Fig.9 Data plate
13 Fig.10 „Igloo" thermostat control panel
14 Fig.11 „Carel" thermostat control panel
14
15
15
16
List of tables
17
17
Table 1 Technical data
18
en
en
11
12
12
13
13
14
14
15
16
17
18
11
