Dimensions; Technical Data; General - Pfannenberg Quadro LED-HI-3G/3D Betriebsanleitung

en

3. Dimensions

Mounting screw
e.g. M4x20
4.

Technical data

4.1

General

Light intensity *
Light source
Service life
Duty cycle
Protection type
Impact strength
Protection class
Operating temperature
Storage temperature
Max. rel. air humidity
Cable inlet
Connecting terminals
Housing material
Lens material
Installation position
Lens colors
* The light intensity may be reduced depending on the lens color and operating mode.
05/2019
Quadro LED-HI-3G/3D Operating Instructions
Sealing screw
M20x1.5
max. 75 cd (Blondel + Rey)
Spring balancer bracket 0.13 - 2.5mm²
Polycarbonate (PC) light gray, RAL 7035
transparent, white, yellow, amber, red, green, blue
Page 2 / 8
Drilling pattern; view from
Cable gland
M20x1.5
4 high-performance LEDs
> 50 000h
100 %
IP 66/67 (EN 60529)
IK 08 (EN50102)
II
- 20 °C .... + 55 °C (T6)
- 40°C...+ 70°C
90%
2x M20 x1.5
Polycarbonate (PC)
any
below
Fixing bracket
086200013
