Follow the below procedure if the no water is
being pumped or flow is reduced:
1 - Release the Foam Cover by pushing the two
buttons (Fig 5-R) and lift the cover (Fig 6-S).
2 - Remove the foam (Fig 7-T), biomedia (Fig 7-U)
and stone bag.
3 – Turn the unit over and remove the 4 fixing
screws (Fig 10-AA) and lift the base clear.
4- Remove the 2 fixing screws (Fig 10-BB) and lift
the Pump Assembly clear.
5 - Twist the Pump Chamber anti-clockwise (Fig
10-CC) and lift clear. The rotor can now be pulled
out for cleaning or replacement ( Fig 10-DD).
Important! Take extra care so as to not drop any
of the small components. See Fig 10A for
assembly of the EasyClear 6000 rotor and Fig 10B
for assembly of the EasyClear 9000 rotor.
6 - Reassemble the pump and 2 off fixing screws
(Fig 10-BB).
7 - Reroute the cable (Fig 10-EE).
8 - Reassemble the filter, and restart.
All Year Pump Care
A quick daily check should be carried out to
ensure that the pump is performing satisfactorily.
Once a week- Remove the outer casing and
Fountain Head in accordance with the general
maintenance notes. Depending on pond water
conditions, cleaning may be required more
frequently.
Winter Storage
When not in use, the unit should be removed,
thoroughly washed and cleaned, dried and
stored in a dry frost protected area. Always store
the unit with the foam and foam cover off to
ensure adequate ventilation and drying.
Spare Parts
(Refer to Fig 11).
Contact the Consumer Services Helpline on +44
(0)121 313 1122
1. Foam (single)
2. UV Lamp (3006)
UV Lamp (3009)
3. Quartz Tube Assembly
4. Pump rotor (3006)
Pump rotor (3009)
29/8/08
14:00
5. Fountain and extension
segment bagged set
Fish Stocking Rate and
Under normal conditions, the Under normal
conditions, the EasyClear™ will support up to
1.44m (EasyClear 6000) or 2.16m (EasyClear 9000)
of fish. Introduce fish slowly over the first few
weeks, up to 20% of the maximum
recommended level, increasing to 50% after six
months. The balance will allow for fish growth.
Clearwater Guarantee
We guarantee you Clearwater or your money
back!
This guarantee runs for 12 months after
purchase, provided that:
• You have followed the installation and
operating instructions
• You are using equipment of the correct size
and stocking level for your pond
• You consult our Helpline +44 (0)121 313 1122
early enough for any problems to be put right
• The product has been returned undamaged. A
refund can only be authorised by Hozelock
Cyprio and is made at the place of purchase.
3 Year Product Guarantee
If this unit, excluding the Rotor Assembly, Filter
Foam & UV Lamp becomes unserviceable within 3
years of the date of purchase it will be repaired
or replaced at our option free of charge, unless
in our opinion it has been damaged or misused.
Liability is not accepted for damage due to
accident, improper installation or use.
Liability is limited to replacement of a faulty unit.
This guarantee is not transferable. It does not
affect your statutory rights.
To obtain the benefits of the guarantee, firstly
contact Hozelock Cyprio Consumer Services who
may request that the filter is sent along with
Item
proof of purchase directly to the address
Numbers
provided.
1408
DAMAGE CAUSED BY RUNNING THE EASYCLEAR
1520
OUT OF WATER OR BY FROST INVALIDATES THE
GUARANTEE.
1541
1556
1461
3439
