INSTALLATION AND OPERATING
INSTRUCTIONS. READ INSTRUCTIONS
CAREFULLY BEFORE ATTEMPTING INSTALLATION.
KEEP THESE INSTRUCTIONS FOR FUTURE
REFERENCE
The Hozelock Cyprio EasyClear™ Fountain and
Waterfall pump is designed for submersible use
in outdoor ponds. It is an integrated unit that
provides Mechanical & Biological Filtration with
an Ultra Violet Clarifier, Fountain and Waterfall
outlet.
General Safety & Guidelines
The appliance is not intended for use by persons
(including children) with reduced physical,
sensory or mental capabilities, or lack of
experience and knowledge, unless they have
been given supervision or instruction concerning
use of the appliance by a person responsible for
their safety. Children should be supervised to
ensure that they do not play with the appliance.
Do not operate or leave the unit in freezing
conditions.
Do not switch the pump on out of water! The
water level should be above the UVC indicator at
the ball joint (Fig 1-A).
DO NOT OPERATE THIS UNIT WITHOUT THE
OUTER CAGE ATTACHED. USING THE UNIT
WITHOUT THE OUTER CAGE MAY INVALIDATE
YOUR WARRANTY.
The clear tube inside the unit is made from
quartz glass and care should be taken during
installation and maintenance. We recommend
the use of eye protection and suitable gloves.
UV Caution
The EasyClear 6000 is fitted with a 9W UVC lamp
and the EasyClear 9000 has a 13W UVC lamp.
Exposure to Ultra Violet (UV) radiation can be
dangerous and cause damage to eyes and skin.
Under no circumstances should any attempt be
made to gain access to the lamp when the unit is
switched on. When switched on, the lamp can be
checked for operation by looking for a bluish
glow from the ball joint outlet (Fig 1-A). Please
note that this may only become visible in low
light conditions.

Overload Protection

To help ensure your EasyClear's long life and to
prevent damage, it is fitted with automatic
29/8/08 14:00 Page 5
thermal Overload Protection. This switches the
pump or UV lamp off if either overheats. If this
occurs, switch off the power at the mains supply
to the unit. If it is the pump that has activated
the Overload Protection, check for the cause (it is
usually debris blocking the inlet of the pump or
obstructing the impeller). Remove the
obstruction and wait 15 minutes for the unit to
cool down and. Then switch it on again.
If it is the UV lamp that is activating the
Overload Protection (pump is still running but UV
lamp keeps going out after running for a short
time), please contact Hozelock Consumer Services
Helpline on +44 (0)121 313 1122.
NOTE: YOU MUST SWITCH OFF THE MAINS
SUPPLY BEFORE THE UNIT WILL RESET.
Periods of Operation
Keep the filter working 24 hours a day. Ideally it
should run all year round, but at least
throughout the fish-feeding season, (i.e. until the
water temperature falls below 10°C and the fish
stop feeding). In winter, operating the unit will
maintain a basic level of useful bacteria in the
Biological Filter, and will help prevent the pond
icing over. However, the unit must not be
allowed to freeze. If you switch the unit off for
winter, wash the unit thoroughly before
resuming filtration in the spring (see 'Winter
Storage'). Never feed your fish when the unit is
not in use.

Electrical Safety

• ALWAYS UNPLUG OR DISCONNECT ALL
APPLIANCES IN THE POND FROM THE
ELECTRICITY SUPPLY BEFORE PUTTING YOUR
HANDS IN THE WATER WHILST EQUIPMENT IS
BEING INSTALLED, REPAIRED, MAINTAINED OR
HANDLED.
• Do not use the supply cable to lift the unit, as
this may cause damage. We recommend fitting a
lifting cord to the hook feature on the base,
when the filter is installed in deep water. (Fig 1-
F).
• Check that the voltage marked on the unit
corresponds to the mains supply.
• A 10mA OR 30mA RESIDUAL CURRENT DEVICE
(RCD) MUST BE FITTED TO THE MAINS SUPPLY.
• The pump is supplied with 10m of 3 core
electric cable which is permanently connected
and sealed to the pump. The supply cable cannot
