be replaced. If the cable is damaged, the unit
should be discarded. The plug supplied with this
product is not waterproof and must be housed in
a dry, waterproof enclosure.
• The installation must conform to the national
and local wiring regulations which could include
the use of plastic or metal conduit to protect the
cable.
• The unit cable should be positioned and
adequately protected against damage especially
where contact with gardening equipment (lawn
mowers, forks etc.) children and domestic
animals may occur.
Installation
Position - Construct a solid and level platform on
which to place the EasyClear™. The platform
should be greater than 300 mm (12") below the
water level. For depths between 300mm and
600mm use the fountain stem extension
segments (Fig 1-K), which simply screw together,
to allow the fountain to be above the water
level. For general installation see Fig 4 A/B.
When using the EasyClear for a waterfall the
entire unit should be submersed.
Connection - Place the unit next to the pond and
route the cable back to the mains supply. Ensure
that you allow for enough cable for positioning
the product in the desired location in the pond.
Accessory Assembly
Bell Fountain (Fig 1).
Locate the Bell Support (B) to the Bell Main Body
(C) and push fully home. Position the Bell (D) to
the Body Assembly and press into the central
location. Insert this into the Fountain Flow
Adjuster (Fig 1-H).
2 and 3 tier fountain display assembly (Fig 1-G).
The plastic discs that create the 2 and 3 tier
water displays simply snap onto the fountain
stem. Push the fountain stem into the fountain
stem extension segment and screw onto the
Fountain Flow Adjuster (Fig 1-H).
Fountain Only Operation
Please note: It is not possible to completely close
off the waterfall outlet (Fig 1-I). This is to allow
water to always bypass in to the pond even if
the fountain head becomes blocked ensuring
clear water. If the pond water is not clearing
sufficiently it may be necessary to allow more
29/8/08 14:00 Page 6
water to bypass in to the pond by opening the
waterfall outlet.
The 2 and 3 tier fountainheads simply snap onto
the fountain stem. The fountain angle can be
adjusted to be vertical using the ball joint (Fig 2-
L). The tightness of the ball joint can be adjusted
(Fig 2-M) if required, the 2-Tier Fountainhead can
be used to achieve an alternative and higher
display pattern than the 3-Tier.
The fountain height can be adjusted to suit your
needs by rotating the Fountain Flow Adjuster
(Fig 3B-N). Turn the Waterfall Adjuster (Fig 3A-O)
until closed to obtain the maximum fountain
height.
The Bell Fountain creates a decorative 'water
bell'. The size of the bell can be adjusted to suit
your needs by rotating the Fountain Flow
Adjuster (Fig 3B-N).
Install and position the pump as previously
described and switch on.
Fountain and Waterfall
Attach a suitable length (3m maximum) of 25
mm (1") hose to the hose tail on the Waterfall
Adjuster (Fig 3A-Q) and secure with a suitable
hose clip and position the outlet end of the hose
in the desired position.
Screw the Waterfall Adjuster onto the waterfall
outlet on the front of the EasyClear™ (Fig 3A-Q).
Once the pump is operating the flow of the
waterfall and the height of the fountain can be
independently adjusted using the Fountain
Adjuster (Fig 3B-N) and Waterfall Adjuster (Fig
3A-O).
Install and position the pump as previously
described and switch on.
Waterfall Only Operation
(Fig 4 for general installation guide)
Screw the blanking plug onto the fountain outlet
(Fig 3A-P).
Attach a suitable length (3m maximum) of 25
mm (1") hose to the hose tail on the Waterfall
Adjuster (Fig 3A-O) and secure with a suitable
hose clip and position the outlet end of the hose
in the desired position.
Screw the Waterfall Adjuster onto the waterfall
outlet on the front of the EasyClear™ (Fig 3A-Q).
Operation
