default display is shown after the camera has been switched off and then
switched on again.

Video-out function

You can use this function, for example, to display the images of the camera on
a TV. Depending on the device on which you want to perform the playback,
you will require a connection cable which must have a 3.5mm jack plug on
one side for connecting to the video-out socket [10] of the endoscope camera.
The other connector may vary depending on your playback device. For further
details, please read the user manual for your playback device. A video cable
[C] with an RCA connector is supplied with the endoscope camera.
To use the video-out function, proceed as follows:

Switch off the endoscope camera.

Connect the video-out socket [10] of the endoscope camera with the
supplied video cable [C] or with a suitable connection cable to your
playback device. Note the corresponding user manual to adjust your
playback device correctly.

Switch on the endoscope camera with the on/off switch [3]. The image is
now displayed on both the screen of the endoscope camera and on your
playback device.
Please note that pressing the view/rotate image button [4],
zoom function [7] or brightness adjustment display button [8]
only affects the screen display of the endoscope camera.
Pressing these buttons is irrelevant for the display of the
playback device in use, for example, TV.
