MRS ELECTRONIC
DATENBLATT MICROPLEX 7H 1.133
PIN - ÜBERSICHT
Pin
Signal
1
3
6
AI_KL15
DO_POWER Self holding, even when Pin X101.6 is off
BLOCK DIAGRAMM
I OFF = 500uA
+/-33V
SMCJ33CA
KL15 Battery/Ignition
CAN_BUS
DO_POWER
Seite 4 von 9
Pin
Digital output
2
DO_OUTPUT_6
7
DO_OUTPUT_7
8
DO_OUTPUT_5
9
DO_OUTPUT_4
10
DO_OUTPUT_3
11
DO_OUTPUT_2
12
DO_OUTPUT_1
ECU
Freescale S08DZ60
Clock frequency:8 MHz
Flash: 60 K
RAM: 4 K
EEPROM: 2 K
Power Supply
Description
Ground
Supply voltage
Ignition
+5V
RST
©MRS Electronic GmbH & Co. KG
Outputs
PWM output
PWM_OUTPUT_6
PWM_OUTPUT_5
PWM_OUTPUT_4
PWM_OUTPUT_3
PWM_OUTPUT_2
PWM_OUTPUT_1
Interfaces
Pin
Signal
Description
4
CAN_L
CAN Bus low
5
CAN_H
Can Bus high
Freescale
S08DZ60
Current sense HSD intern
Current sense HSD intern
Änderungen vorbehalten
VNQ5050
VNQ5050
Version 1.2
