Gigabit Ethernet Switch User's Guide
The LED indicators for PC connection are dependent on the
LAN
card
capabilities.
If
LED
indicators
are
not
illuminated after making a proper connection, check the
PC's
LAN
card,
the
cable,
Switch
conditions,
and
connections.
The following are LED indicator possibilities for a PC to
Switch connection:
♦ The Link/Act LED indicator lights up upon hookup.
Switch to Switch (other devices)
The Switch can be connected to another switch or other
devices (routers, bridges, etc.) via a fiber optic cable.
Figure 4-2. DGS-3204 Switch to switch connection.
16
Connecting The Switch
