3. Layout & Connections

3.1 Layout

Upstream B-Port
Power LED
4x USB 2.0
Downstream A-Port
(screw lock)

3.2 Connections

5V Connector:
© Copyright 2018 by EXSYS Vertriebs GmbH. All Rights Reserved
1x USB 2.0
(screw lock)
Status LED
for each Port
ATTENTION!!!
Use only with Power Supply which is included in delivery!
5V Connector
(screw lock)
for included external
Power Supply
