5. Depress the spring clip in the lower stem
to adjust to the most comfortable opera-
ting length.
7. Insert the cable connector into the con-
nector of control housing and handtigh-
ten.
Overview
1 Lower Scale
2 Upper Scale
3 Sensitivity Indicator
4 Target ID Legend
5 Target ID Cursor
6 Battery Condition Indicator
7 Coin Depth Indicator
14

Control Panel and Controls

6. Wrap the searchcoil snugly about the
stem with the first turn of the cable over
the stem.
8. The location of the arm cuff may be ad-
justed by removing the screw on the
bottom and moving it to the other hole.
