auna multimedia TC-386 Bedienungsanleitung Seite 22

• Remove the stylus protector. Make sure that the tone arm is being detached from the tone arm rest
before operating and that it is re-secured again afterwards.
• Select to " Phono " function (6). Then press the BT/Phono button (17) to "PHONO" position.
• Set the speed selector to the proper position depending on the record to be played.
• Place the record on the platter (use the spindle adaptor if required).
• Lift the tone arm from the rest and slowly move it to the record side. The platter will start to rotate.
• Place the tone arm to the desired position of the record.
• Adjust the volume to the desired level.
• At the end of record, the platter will automatically stop rotating. Lift the tone arm from the record and
return it to the rest.
• To stop manually, lift the tone arm from the record and return it to the rest.
Remarks: As some kind of record the auto-stop area was out of the unit setting, so it will stop before the last
rack finish. In this case, select the auto-stop switch to " off " position, then it will run to the end of the record
but will not stop automatically (turn off the power button or switch back the auto-stop switch (34) to " on "
position to stop the platter rotate). Then put back the tone arm to the rest position.
Connect the system to your hifi system by connecting the line out socket (32) to the auxiliary input socket
with an RCA cable (not included).
General operation
Stop / eject key
Fast forward key &
Fast rewind key
Play key
Pause key
Record key
(deck 1 only)
22
Phono
Line Out Connection
Tape Deck
Press to stop all deck operation. Press again to open the cassette door.
Press to start rapid tape winding in either forward or revers direction. Press
stop / fast rewind key eject keys when the cassette spools stop turning.
Press to start playing tape.
Press to stop tape operation temporarily. Press again to resume play.
Press together with play key to start tape recording.
