GB
Transport
– Use the original packaging to ship whenever
possible.

Troubleshooting

If something doesn't work...
DANGER! Risk of injury! Improper repairs
can result in the product functioning
unsafely. This endangers yourself and your
environment.
Fault/malfunction
Motor does not start.
Motor misfires when running
Motor does not reach the maximum
speed
Abnormal noise.
The drill is rotating at idling speed. Clutch defective.
If you can't fix the fault yourself, contact your nearest
vendor. Please be aware that any improper repairs
will also invalidate the warranty and additional costs
may be incurred.

Disposal

Disposal of the appliance
WARNING! Risk of fire or environmental
damage! Avoid damage caused by leaking
fuel: drain the tank prior to disposal.
This appliance must not be disposed of with regular
household waste! Dispose of the appliance in the
appropriate manner. For more information, consult
your community waste disposal service.
18
Malfunctions are often caused by minor faults. You
can easily remedy most of these yourself. Please
consult the following table before contacting the
vendor. You will save yourself a lot of trouble and
possibly money too.
Cause
Tank empty?
Ignition cable connector loose?
Ignition cable connector contami-
nated?
Spark plug contaminated?
Spark plug defective?
Excess fuel in the combustion
chamber?
Distance from electrode to spark
plug too great?
Incorrect fuel?
Cold-start lever to [ ]?
Air filter contaminated?
Spark plug contaminated?
Distance from electrode to spark
plug too great?
Incorrect fuel?
Screws/parts looses?
Foreign objects in the drill?
Drill damaged?
Disposing of fuels and lubricants
Waste fuels, waste oils, and materials containing oils
(air filter, rags, etc.) may not get into the environment.
– Bring waste materials that could damage the
environment to a collection point of the dealer or
in your community.
Disposal of the packaging
The packaging consists of cardboard and
correspondingly marked plastics that can
be recycled.
– Make these materials available for
recycling.
Remedy
► Filling with fuel – p. 15
Push the connector firmly onto the
spark plug.
Clean connector.
► Cleaning/replacing the spark
plug – p. 17
Motor starts several times without
pressing the choke (Position [
If the motor will not start: Take out
the spark plug and dry the elec-
trode.
Set gap at 0.7-0.8 mm.
Drain tank and fill up with the correct
fuel.
Set the cold-start lever to [
► Cleaning the air filter – p. 17
► Cleaning/replacing the spark
plug – p. 17
Set gap at 0.7-0.8 mm.
Empty tank and fill up with the cor-
rect fuel.
Re-tighten the screws.
Remove foreign objects.
Replace the drill.
Contact your local vendor.
]).
].
