6. APPENDICES (continued)
ECP 15
N Ref.
1 HWX32009210196 Front ABS panel
2 HWX20003933
3 HWX20003524
4 HWX35122213
5 HWX320921015
6 HWX320921149
7 HWX32009210193 Frame
8 HWX35002701
9 HWX34043301
10 HWX32009210195 Left panel
11 HWX320921147
12 HWX320921148
13 HWX20013605
14 HWX200014153
15 HWX32009210197 Top ABS cover
16 HWX20001489
17 HWX20011491
18 HWX20003603
19 HWX20003242
20 HWX351212001
21 HWX20041444
22 HWX200036005
32
Description
3-point terminal block
Start-up capacitor
CPS 98µF
Grille
Front stiffener
Rear stiffener
Fan blade
Fan motor
Motor bracket
Centre wall
High pressure switch
Schräder valve
Restrictor
4-way valve
Low pressure switch
Temperature sensor
Coil
Filter (diam. 9.7- diam.
9.7)
Flow detector
N Ref.
23 HWX20003242
24 HWX20003242
25 HWX32091206
26 HWX35001401
27 HWX20002111
28 HWX950531188
29 HWX32009210194 Right panel
30 HWX20003242
31 HWX32009220054 Protection cover
32 HWX20011169
33 HWX320921152
34 HWX320921151
35 HWX20003501
36 HWX200037006
37 HWX20003920
38 HWX950531145
39 HWX20003676
40 HWX200036007
41 HWX20003909
42 HWX20003510
43 HWX20009909
Description
Temperature sensor
Temperature sensor
Titanium/PVC
capacitor
Battery
Controller protective
cover
7-segment controller
Temperature sensor
Compressor
Electrical box cover
Electrical box
Fan capacitor 3µF
230V~/12V~
transformer
3-point terminal block
PC1000 circuit board
Relay
Compressor switch
2-point terminal block
Compressor capacitor
60µF
Capillary
