iLOFT MONITOR OPERATION
EN
Buttons
Audio Activation, Call Hang-Up and Configuration Settings Button (menu).
· When a call is received, press this button to speak to the visitor. The audio
channel between the entry panel and the residence is opened; operating in
hands-free mode.
· Press to end communication.
· With the monitor on standby, press and hold this button for 3 seconds to go into
monitor configuration mode. See the «Monitor Settings» section.
Lock Release / Call Guard Unit Button
· Pressing this button whilst communicating with the Entry Panel will activate the lock
release.
· Pressing this button whilst the monitor is on standby will result in a call being made to the
guard unit (where one exists).
Auto-Start / Main-Secondary Camera Selection Button.
· With the monitor on standby, press and hold this button for 1 second to switch the
monitor on manually. To activate audio functions, press the
· With video, press and hold this button for 2 seconds to sequentially select between the
main camera and the secondary camera (where one exists).
F1 and F2: Buttons for Additional Functions. (Assigned by the installer).
Led
Led Status
1 Flash every second.
Red
1 Flash every 2 seconds.
On, green .
Green
Green
On, alternating between green and red.
Red
Blue: On, blue .
Pag 32
Led
Buttons
Monitor Status
In Programming or Settings Mode.
Ring Tone Cancelled Option Activated.
«Automatic Release» Mode Activated.
Call Tone Cancelled and «Automatic
Release» activated.
Communication Established / Channel
Busy.
button.
