SYSTEM FUNCTIONS

Doorbell
If somebody presses the doorbell on the external station, your doorbell
chime will ring on the indoor unit, and the speak and door-release
buttons will flash for approx. 60 seconds.
Voice communication
To be able to talk to the visitor, press the voice button once briefly.
You now have a voice connection, and the luminous surround of the
voice button will light continuously as you talk. To terminate voice
communication, give the voice button another short press. You can
re-establish the voice connection at any time. The bell does not need to
be rung first.
Door opening
A linked door opener is activated for approximately six seconds by
briefly pressing the door opener button. You do not have to hold the
door opener button down. Confirmation is provided by a double beep
sound at the external and internal unit, and the name tag lights up
green for the time the door opener is activated.
The door release mechanism can be activated if:
1. somebody rings the doorbell (within 60 seconds and without having
to establish voice communication first);
2. the reply function is on.
Set the doorbell chime
1. Press the speak button.
2. Press the chime button to play the chime set.
3. Press the chime button to play the next chime and repeat this
process until you find the chime you want.
4. Press the speak button to save the chime.
Own melody on memory card
This intercom system offers the possibility to select your own ringtones,
which are stored in MP3 or WAV format on a micro SD card. The memo-
ry card must be formatted with FAT32. You store your ringtones directly
on the SD card (without using folders). Insert the prepared SD card into
the SD card slot (23) on the board. The ringtones on the memory card
replace the internal ringtones. When the memory card is removed, the
internal melodies are available again.
There are 12 different chimes to choose from.
Set the handset volume
Use the handset volume control on the side of the indoor unit to
infinitely adjust the handset volume of the person at the other end.
Set the doorbell volume
The volume can be infinitely set between 0% and 100% using the doo-
rbell volume control on the mainboard (adjust the volume with a small
screw driver; turning clockwise to increase the volume and anticlockwise
to decrease it). Be careful not to overtighten the potentiometer.
ADV-100_I-Manual_210x260_Fin7.indd 7
Disable the doorbell chime (e.g. at night)
The doorbell chime can be disabled. To do this, press the sleep button
on the indoor unit once. The LED below the sleep button flashes red to
show that the chime has been disabled. To activate the chime again,
press the sleep button again; the LED will stop flashing and the chime
will be reactivated.
The optical signal (light surrounding the speak and door release
buttons) remains activated even if the doorbell chime is disabled and
continues to indicate that the doorbell has been pressed.
NOTE: If the VTX-BELL module is used, this will also be
disabled during sleep mode, i.e. the signal from connected
receivers is also disabled.
Activate alarm
The external station can sound an alarm (e.g. if you are being
harassed). To do this, you have to press and hold the alarm button on
the indoor unit. The alarm only sounds if the button is pressed and
held down within 60 seconds after the doorbell was pressed or if voice
communication is established.
Intercom
If several indoor units are connected in parallel, you can communicate
between these indoor units.
If you press the alarm button when the station is on standby, all indoor
units connected in parallel will sound the alarm. Voice communication
is established if the handset is lifted on one of the ringing indoor units
or the speak button is pressed. To end the call, either put the handset
down or press the speak button.
CONNECTION OPTIONS AND OPTIONAL ACCESSORIES
External push button
On the internal unit, a floor push button (standard bell push button)
can be connected. It is connected to the corresponding terminals (40
and 41, s. Fig. 3).
Radio forwarding
As an optional accessory, the radio module model VTX-BELL is available,
which allows forwarding the radio door bell system BELL. This module is
simply attached to the connector (22) and then forwards the signal by
radio to the corresponding receiver when ringing.

TECHNICAL DATA

Operating voltage: 15 V DC
Current consumption: 220 ± 50 mA
Temperature range: -10°C to +50°C
Maximum humidity: 85%
