• If a perfect result ist still not achieved even after scraping twice.
a) Check the feed setting at the markings.
b) Check the scraper blade (3) and if necessary replace it (see chapter 8).
An abrasion of the blade can enlarge the swarf thickness inadmissibly. This
abrasion occurs because of multiple usage and outside influences (sand, soil
etc.). Therefore the strength of the swarf must be measured regularly - e.g.
with a calliper gauge. Scraper blades are worn parts and have to be replaced
(see chapter 8).
NOTICE
Scrape twice at a maximum!
NOTICE
An incomplete scraping or a differing swarf thickness may result in a leaking
fusion joint.
8.

Replacement of blade

CAUTION
Risk of injury at the blade!
NOTICE
Please note when replacing the blade that only blades dyed red may be used!
• Release the TORX screw with the TORX spanner supplied.
• Remove the blade and clean the supporting surface carefully.
• Insert a new blade.
• Tighten the TORX screw with the torx spanner.
Item
FWSGE 3/Replacement blade set
Order-No.
613322
EN
17
