EN
CAUTION
Risk of injury during scraping process!
Keep hands off the pipe.
NOTICE
Press the scraper tool against the end of the pipe while scraping in order to
avoid tilting of the tool in axial direction.
• The swarf is to be removed manually.
6.
Disassembly of the scraper tool
• Release the twist grip knob (5) by turning it anti-clockwise.
• Pull the scraper tool off the pipe end.
• After use, store the tool in the transport box.
7.
Inspection of the scraping result
Inspect the scraping result, i.e. the swarf must be completely removed and the
markings applied before with the FRIALEN marker may no longer be visible.
For bundled coil pipes control the scraping result with regard to the swarf
thickness or remained marks on the pipe very carefully.
The blade (3) is adjusted for a swarf strength of 0,25 – 0,35mm. For the scrap-
ing of FRIALEN safety fittings the wear limit is max. 0,4mm and must not be
exceeded. Please note differing requirements of other fitting manufacturers.
If the marker lines are not completely removed, the scraping process should
be repeated.
NOTICE
Scrape twice at a maximum!
16
