Settings overview

The settings for the orientation light and odour extraction unit can be modified.
The menu is indicated by the colour of the odour extraction unit indicator light on the right
side.
The settings are indicated by the colour of the orientation light on the left side.
Table 1: Settings overview
Menu
(White)
Light colour
(Blue)
Conditions for
switching on
orientation light
(Turquoise)
Conditions for
switching off
orientation light
(Magenta)
Odour extraction unit
run-on time
(Orange)
Detection distance
(Yellow)
Odour extraction unit
14
Settings (bold = factory setting)
The following light colours can be selected:
• blue, turquoise, magenta, orange, yellow, warm white and white
Three different settings are possible:
• switch on when a user is detected and the ambient conditions are
dark (blue)
• switch on when a user is detected (always, regardless of
ambient light) (turquoise)
• off (orientation light is not switched on) (magenta)
Time after which the orientation light automatically switches off when
user detection is not activated:
• 1 minute (blue)
• 3 minutes (turquoise)
• 6 minutes (magenta)
Time after which the odour extraction unit automatically switches off:
• 5 minutes (blue)
• 10 minutes (turquoise)
• 15 minutes (magenta)
Distance at which a user is detected:
• near (blue)
• medium (turquoise)
• far (magenta)
Automatic or manual starting of odour extraction unit:
• switch on automatically when user is detected (blue)
• switch on by pressing <Odour extraction> button (turquoise)
