UHF Wireless Microphone System | Installation and User Instructions |
3.2

Handheld microphone

1 Dynamic capsule
2 Battery tray
3 Battery tray release switch
4 Power ON/OFF switch
5 Rotary wheel for frequency, sensitivity and lock
selection
6 LCD
3
6
figure 3.4: Handheld microphone
Bosch Security Systems | 2006-01 | 9922 141 50701ml
2
4
5
LCD
1 Frequency indication and menu options
2 Battery status indication
1
2
1
figure 3.5: Handheld microphone LCD
3.3

Lavalier microphone

1 Microphone
2 Clip
3 Mini XLR
4 Windscreen
1
figure 3.6: Lavalier microphone
2
3
4
en | 11
