ORDER:

Type Version
2255 Fixed.
Programmable.
aNaLOGuE OuTPuT PROGRaMMING bY WaY OF juMPERS:
Output range
0...10.mA.(current.only)
0...20.mA.(current.only)
0...10.mA./.0...0.5.V
0...20.mA./.0...1.0.V
0...10.mA./.0...5.0.V
0...20.mA./.0...10.0.V
Special.voltage.output:
(Resistor.R38.mounted)
42
Output
:.A Analogue.+.NPN.output. :.1
:.B Analogue.+.relay.output. :.2
jP3 jP2 jP1
OFF - -
ON - -
OFF OFF ON
ON OFF ON
OFF ON OFF
OFF
ON ON
ON.or
OFF OFF OFF
bLOCK DIaGRaM:
43
