Model
Input(Ph)
10000
15000
20000
30000
NOTE 1: The cable for 10kVA should be able to withstand over 40A current. It is recommended to use
AWG 10 or thicker wire for Phase and AWG 8 or thicker wire for Neutral for safety and efficiency.
NOTE 2: The cable for 15kVA should be able to withstand over 63A current. It is recommended to use
AWG 8 or thicker wire for Phase and AWG 6 or thicker wire for Neutral for safety and efficiency.
NOTE 3: The cable for 20kVA should be able to withstand over 63A current. It is recommended to use
AWG 8 or thicker wire for Phase and AWG 6 or thicker wire for Neutral for safety and efficiency.
NOTE 4: The cable for 30kVA should be able to withstand over 63A current. It is recommended to use
AWG 8 or thicker wire for Phase and AWG 4 or thicker wire for Neutral for safety and efficiency.
NOTE 5: The selections for color of wires should be followed by the local electrical laws and
regulations.
5)
Remove the terminal block cover on the rear panel of UPS. Then connect the wires according to the
following terminal block diagrams: (Connect the earth wire first when making wire connection. Disconnect
the earth wire last when making wire disconnection!)
Wiring spec (AWG)
Output(Ph)
10
10
8
8
8
8
8
8
Terminal Block wiring diagram of 10000-20000 CP
Terminal Block wiring diagram of 30000CP
Neutral
Battery
8
8
6
6
6
6
4
4
7
Ground
8
6
6
4
