WIRING INSTALLATION

Power, Alarm and Control Connections
EARTH BAR
MOUNT
F-LT-EB
EARTH BAR
(OPTIONAL)
POWER AND
ALARM
CONNECTIONS
EARTH BAR
MOUNT
MODULE MOUNT
F-LT-PMB
MODULE MOUNT
KIT (OPTIONAL)*
MODULE MOUNT
*If required, an input/output module
can be installed into the FAAST LT
unit. The optional module mount kit
(F-LT-PMB) will be needed for this.
N200-102-00
4
6
CHANNEL 1 FILTER CHANNEL 2 FILTER
PLACE
WIRING
LABEL
HERE
USB PORT
SENSOR COVER
POSITION FOR
TEST MAGNET
Exhaust Pipe
Whenever the FAAST LT is installed outside the risk area, return of
the exhaust air back into the protected area can reduce flow faults
due to pressure difference.
P P
P
!
If the FAAST LT door is closed for a long time
(especially at high temperatures) it may be
necessary to use a flat-bladed screwdriver
between the two tabs at the top of the unit to
lever open the door (as shown above).
Figure 9: Inside the Detector
Note 1: All wiring should comply with local
requirements and regulations.
Note 2: Loop wiring must observe the
recommendations of the panel manufacturer
4
SAMPLING AREA
SAMPLING AREA
I56-3947-202
