Abus TVCC50011 Bedienungsanleitung Seite 29

MANUAL
PUSH LOCK
BACKLIGHT
Function
OFF
BLC
HLC
PICT ADJUST
Function
MIRROR
BRIGHTNESS
CONTRAST
SHARPNESS
HUE
GAIN
ATR
Function
ATR
PRIVACY
Manueller Weißabgleich
LEVEL (0~36): Setting for manual white balance.
Push Lock
The white balance measurement will be performed by pressing
the „Enter" button on the control board, and will be stored.
Description
The back light handling is turned off.
The conventional back light compensation function is activated.
(Back Light Compensation)
The function for inversion of too bright image areas into black
color is activated (High Light Compensation). Too bright image
areas will be converted to black areas over certain value (e.g.
car lights).
Description
Horizontal mirror
OFF: Horizontal image inversion is deactive
ON: Horizontal image inversion is active
Brightness (0~255)
Contrast (0~255)
Sharpness (0~255): A high value of sharpness could increase
Hue (0~255)
Gain (0~255):
Description
Settings for the Wide Dynamic Function (Adaptive Tone
Reproduction)
OFF: Wide Dynamic Function deactive
ON: Wide Dynamic Function active
LUMINANCE (LOW/MID/HIGH):
Level of the brightness balance. Dark areas will be
displayed more bright (LOW->HIGH), in addition the
brightness for bright areas will be tried to keep constant.
CONTRAST (LOW/MIDLOW/MID/MIDHIGH/HIGH)
Increasing of image contrast
(LOW->HIGH). A high value can cause detail loss in
dark areas as well as over exposure.
29
the noise level.
Setting for the maximum internal gain
value.
