Specification
Weight approx.
approx. 1,3 kg / 2,9 pounds
Dimensions
:
210mm x 45mm x 185mm / 8,3 x 1,8 x 7,3 inch
2 DMX – OUT
(XLR 5 pin) on the rear side. Each DMX OUT can be individually configured as DMX IN.
Ethernet RJ 45
network connector
USB Port
connector on the front side. For update via USB-stick only. Do not connect any peripheral
device (mouse, keyboard or similar)
2" TFT color monitor
2x DMX Out (MA 2Port Node)
Up to 1 024 parameters (MA 2Port Node onPC 1k)
Up to 2 048 parameters (MA 2Port Node onPC 2k)
MA 2Port Node
Data
Transport
Safety
instructions
Safety and
environment
Quickstart
Connect
Quickstart
ON / OFF
Maintenance
Conformity
25
